DYWIDAG THREADBAR
|
|
| type |
|
|
|
|
THREADBAR
® |
| steel
grade fp0.1k
/fpk
|
|
N/mm² |
|
|
835/1030 |
|
1080/1230 |
|
950/1050 |
| diameter/type |
|
|
|
|
26E |
|
32E |
|
36E |
|
26D |
|
32D |
|
36D |
|
26WR |
|
32WR |
|
36WR |
|
40WR |
| diameter |
|
mm |
|
|
26.5 |
|
32 |
|
36 |
|
26.5 |
|
32 |
|
36 |
|
26.5 |
|
32 |
|
36 |
|
40 |
| nom.
cross section area |
|
mm² |
|
|
551 |
|
804 |
|
1018 |
|
551 |
|
804 |
|
1020 |
|
551 |
|
804 |
|
1018 |
|
1257 |
| weight |
|
kg/m |
|
|
4.48 |
|
6.53 |
|
8.27 |
|
4.48 |
|
6.53 |
|
8.27 |
|
4.48 |
|
6.53 |
|
8.27 |
|
10.21 |
| pitch |
|
mm |
|
|
13.0 |
|
16.0 |
|
18.0 |
|
13.0 |
|
16.0 |
|
18.0 |
|
13.0 |
|
16.0 |
|
18.0 |
|
20.0 |
| ultimate
load fp0.1k
*A |
|
kN |
|
|
568 |
|
828 |
|
1,049 |
|
678 |
|
989 |
|
1,252 |
|
580 |
|
850 |
|
1,070 |
|
1,320 |
| yield
load fpk
*A |
|
kN |
|
|
460 |
|
671 |
|
850 |
|
595 |
|
868 |
|
1,099 |
|
523 |
|
764 |
|
967 |
|
1,194 |
|
| |
 |
|
|
| |
| |
|
